MAX-58 B/D
Maximum welding power: when surface finish, speed and reliability are crucial.
Very high welding capacity for large projects
The 58 B/D offers superior material deposition, designed for welding thick parts or plastic components requiring maximum strength. It allows for much faster welding, reducing time and costs in industrial installations and manufacturing.
Reliable performance during long workdays
It operates reliably even during extended use. It maintains a consistent flow, resulting in strong, uninterrupted, and beautifully finished cords from start to finish.
Precision for demanding jobs
Its independent temperature control ensures that the plastic melts at precisely the right point. This prevents waste, warping, or weak joints and guarantees results that meet high quality standards.
Ideal for heavy industrial applications
Designed for sectors that work with large structures, such as mining, water treatment, geomembranes, and containers. The perfect tool for those who need productivity and durability in a single piece of equipment.
COMPATIBLE WITH PE, PP AND HDPE
HIGH WELDING FLOW RATE
INDEPENDENT TEMPERATURE CONTROL
USES AND APPLICATIONS
- Use 3 and 4 mm rod
- Fast start-up and warm-up
- 360° rotating shoe for different welding positions
- Ergonomic handle for long workdays
- Motor protected against overheating
- Reinforced body for industrial conditions
- Designed for thick materials and bulky parts
MORE DETAILS
- Ideal for manufacturing, repair and on-site assembly
- Welding processes that meet high production demands
TIPS MAX-58 B/D
ELECTRICAL CONNECTION
New equipment has a European connection; ideally, you should have a European female connector. If that's not the case, we'll show you how to connect it to the American system.
To connect it, we share the following specifications:
IMPORTANT:
- Consider the NEMA in which only the physical ground should be connected (Image).
- Ideally, in the industry, you should use a separate thermal switch from your load center (the amperage range can be from 20 to 30 Amps). If you have any questions, please contact technical support.
GENERATOR CONNECTION
In the Americas, generators have a 240v female outlet, and you must identify the NEMA.
Important:
- Once you have identified the NEMA, you must obtain the male that corresponds to the NEMA.
- You just need to connect L1 and L2, which is the equipment voltage, and add "T" ground.
- When purchasing a generator, you should pay attention to 3 important electrical characteristics:
- Watts
- Voltage
- The most important one is how many Amps it delivers per phase.
We recommend having an extension where you can have a MULTI-CONTACT module so you can connect your equipment independently.
MAINTENANCE
How often should you perform maintenance on your equipment?
- Deductive
Applied by the operator
- Tighten the connections periodically.
- Clean the filters daily.
- Purge the device every time you finish your shift.
- It is important to purge with natural polyethylene welding every month.
- Before connecting your equipment, you should leave your generator running for ten minutes to allow it to stabilize.
- Once 10 minutes have passed, every generator should deliver 235 to 240 volts.
- Before doing this, we suggest you always check your line (L1) to ground with a multimeter and L2 using the same procedure; each phase should deliver above 110 volts. If it is less than 70 volts in any of the phases, do not connect your equipment under any circumstances; send your generator to a service center.
- Preventive
Applied by Munsch Engineering
- Preferably every 350 hours of use.
- Corrective
Immediate supervisor in the Engineering department, Munsch
